Standards
- 1. Design and manufacture:BS5150/AWWA C509/DIN 3352.
- 2. Face to face dimensions: ISO 5752.
- 3. Test and inspection: API 598EN12266..
- 4. Size up to 12".
Materials
| No. | Part | Material | No. | Part | Material |
| 1 | Body | C.I./D.I | 4 | Sealing Ring | NBR |
| 2 | Wedge | C.I./D.I. | 5 | Bolt&Nut | S.S./Steel+zinc |
| 3 | Stem | S.S. | 6 | Bonnet | C.I./D.I. |
Dimensions
|
DN |
40 |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
250 |
300 |
|
L |
240 |
250 |
270 |
280 |
300 |
325 |
350 |
400 |
450 |
500 |
|
H |
245 |
278 |
302 |
330 |
337 |
430 |
497 |
600 |
711 |
796 |
